Lewitt MTP 840 DM

Lewitt MTP 840 DM

AMPLIFY YOUR SOUND!
Active Mode – boost your sensitivity
The MTP 840 DM is a supercardioid handheld performance microphone. Its tailored frequency response means that your vocals will cut through every mix. The unique Active Mode boosts sensitivity by up to 12 dB while output impedance stays low. Excellent transient response, refined electronics, and superior capsule design make the MTP 840 DM a unique tool for onstage use.

Specifications
Type
    Dynamic, moving coil
Acoustical operating principle
    Pressure gradient transducer
Polar pattern
    Supercardioid
Frequency range
    40 ... 18,000 Hz
Sensitivity
    3.5 mV/Pa, -49 dBV/Pa
Signal / noise ratio
    75 dB (A)
Equivalent noise level
    19 dB (A)
Dynamic range, passive mode
    135 dB
Dynamic range, active mode
    121 dB  0 dB gain
    115 dB  6 dB gain
    109 dB  12 dB gain
Gain settings, active mode
    0 dB, 6 dB, 12 dB
Low-cut filter
    linear
    150 Hz (12 dB/oct)
    250 Hz (12 dB/oct)
Internal impedance
    600 Ω
Rated load impedance
    1,000 Ω
Supply voltage
    48 V ± 4 V
Current consumption
    5.5 mA
Connector
    Gold plated 3-pin XLR
Microphone dimensions
    51 dia. x 183 mm, 2 dia. x 7.2 in
Microphone net weight
    336 g, 11.85 oz
