Lewitt MTP 940 CM

Lewitt MTP 940 CM

STUDIO PERFORMANCE ONSTAGE
Amazing sound - Acoustic precision
Since it incorporates features of a large-diaphragm multi-pattern condenser microphone into a handheld enclosure, your MTP 940 CM can be used both in the studio and onstage. With its three polar patterns, pre-attenuation and low-cut settings, it is made for a wide range of applications, yet it excels as the perfect microphone for the professional vocalist.

True 1" condenser capsule
The MTP 940 CM uses the same technology as our top-of-the-line studio microphones.
    1" true condenser capsule
    3 polar patterns
    4 micron Mylar dual diaphragm

Specifications
Type
    Condenser, externally polarized
Acoustical operating principle
    Pressure gradient transducer
Transducer Ø
    25.4 mm, 1 in
Polar pattern
    Wide cardioid, cardioid, supercardioid
Frequency range
    20 ... 20,000 Hz
Sensitivity
    10 mV/Pa, -40 dBV/Pa (cardioid)
Equivalent noise level
    9 dB (A), cardioid
Max. SPL for 0.5 % THD
    144 dBSPL, 0 dB pre-attenuation
Signal / noise ratio
    85 dB (A)
Dynamic range
    135 dB (A)
Pre-attenuation pad
     0 dB
    -6 dB
    -12 dB
Low-cut filter
    linear
    80 Hz (12 dB/oct)
    160 Hz (12 dB/oct)
Internal impedance
    150 Ω
Rated load impedance
    1,000 Ω
Supply voltage
    48 V ± 4 V
Current consumption
    5.5 mA
Connector
    Gold plated 3-pin XLR
Microphone dimensions
    51 dia. x 183 mm, 2 dia. x 7.2 in
Microphone net weight
    332 g, 11.71 oz
