DL1608 Wireless Digital Mixer

REDEFINING
LIVE MIXING

The Mackie DL1608 redefined live mixing by combining the proven power of a full-featured digital mixer with the unmatched ease and mobility of devices you already own. Seamless wired to wireless mixing allows control from anywhere in the venue giving you the ultimate control over your mix.

FREEDOM

TO MIX FROM ANYWHERE

Ideal for bands, rental house and production/installations, the DL1608 provides the mobile freedom to wirelessly control the mix and powerful plug-in processing. With boutique-quality Onyx™ mic preamps and the performance of 24-bit Cirrus Logic^® AD/DA converters, you have unparalleled sound quality. The Master Fader control app, the heart of your DL mixer, even supports up to 20 wireless devices. Forget bulky consoles and racks of gear. The power is at your fingertips.

master fader

The Heart of Your Mix

Master Fader is the main user interface for your DL Series mixer. Rather than knobs, faders and buttons on a large piece of hardware, you get powerful mixing tools on your tablet, Mac, or PC and at up to 20 different devices simultaneously. The intuitive design of the Master Fader app makes managing your mix, large or small, easy and efficient. Organize your channels with view and mute groups, utilize subgroups with full bus processing, control levels of channel groups simply with VCAs, and even lock out devices from specific capabilities within the app. And when you get a mix you like, you can save it all into a snapshot.

Powerful Processing

From EQ to compression, every bit of signal processing is implemented with the highest quality possible maintaining the fidelity of each source. Every channel and output bus gets it's own dedicated processing.

The 4-band parametric EQ on each channel and output features a dedicated high-pass filter, modern and vintage modes, and built-in RTA for maximum versatility and detailed analysis of each source. The clear UI makes it easy to make adjustments, view settings, and choose presets.

Each FX processor features tons of studio-quality reverbs and delays plus effects like chorus, tremolo, flanger, and sweep filter. Fine tune each effect with advanced parameters and EQ.

Total Freedom

Complete wireless control via iOS, Android, macOS, and Windows devices means you can mix from anywhere in the venue on up to 20 devices. Wireless control also means you can put the mixer itself where it makes the most sense for application.

DL1608

16-Channel Digital Mixer​

• 16 Onyx^™ mic preamps
• 8 balanced outputs
• High-end Cirrus Logic^® converters
• Ultra low-noise, high-headroom design
• Rugged, compact desktop design with iPad^® dock
• Rackmountable with optional kit

Flexible Wireless or Docked Control

• Mix wirelessly from anywhere in the venue
  • Unmatched wireless control over mix
  • Supports up to 20 devices at once
  • Personal monitor mixing
• Dock your iPad for added features and security
  • Creates and integrated, self-contained desktop mixer
  • Total control over assignable 2-channel recordings for immediate playback and easy exporting
  • Playback music from any iPad app and incorporate into the mix
  • Always keep your iPad charged
  • PadLock^™ feature locks down iPad for security
  • Industry standard Kensington lock secures mixer
  • Dock compatible with iPad (2017), iPad Pro 9.7-inch, iPad Air 2, iPad Air, and iPad (4th generation)
  • Optional tray kits available to fit iPad mini 3, iPad mini 2 and iPad mini

Master Fader Control App

• Proven, intuitive workflow that's customizable for your application
  • Create view groups and see only the channels you need
  • Unique access limiting locks out controls you aren't using
• Export presets, shows and complete system backups
• Quick setup with tons of factory and user-definable presets
• Complete offline operation saves setup time at gig
• Available on iOS, Android™, macOS^®, and Windows^®

Professional, Comprehensive DSP

• Packed with more DSP processing than any other compact mixer
• 18 input channels with 4-band PEQ + HPF, gate, compression and RTA/Spectrograph
  • 16 stereo-linkable input channels
  • 2 stereo-linkable iPad return channels*
• 12 output busses with 4-band PEQ + HPF/LPF, 31-band GEQ, comp/limiter, alignment delay and RTA/Spectrograph
  • 6 stereo-linkable aux sends
  • 4 stereo-linkable subgroups*
  • Main L/R busses
• 4 VCAs and 4 mute groups
• 2 stereo FX processors with dedicated sends and returns
• Choice of powerful, touch-sensitive modern and vintage plug-ins

Record and Produce Like a Pro

• Pro Tools® | First and Waveform™ OEM professional software and plugin packages included
• The Musician Collection for ProTools | First includes 23 plugins like BBD Delay, Eleven Lite, 304E EQ, and 304C Compressor
• The DAW Essentials™ Bundle for Waveform OEM includes 16 powerful plugins like Equaliser, Compressor, Reverber8, and Limiter

DL1608 is compatible with iOS 11 or later, Android OS 6 or later, macOS 10.12 or later, and Windows 10 or later when using the latest Master Fader 5.x software

*iPad return channels and subgroups feature PEQ and compression.

Wi-Fi router required for wireless operation. Wi-Fi router and control device not included.

Tech Specs

• Type: Digital
• Channels: 16
• Inputs - Mic Preamps: 12 x XLR, 4 x Combo
• Phantom Power: Switchable
• Inputs - Line: 12 x XLR, 4 x Combo
• Outputs - Main: 2 x XLR
• Send/Return I/O: 6 x TRS (Sends)
• Aux Sends: 6 x Aux Sends
• Busses/Groups: Software-controlled
• Data I/O: Ethernet (WiFi Router Not Included)
• Headphones: 1 x 1/4"
• EQ Bands: 4-band Fully Parametric (Per Channel), 31-band Graphic Master Bus
• Effects: Yes (Compression, Reverb, Delay)
• Software: Master Fader Control App (iOS 11 or later, Android 6.0 or later, macOS 10.2, Windows 10)
• Rackmountable: Yes (via Optional Kit)
• Height: 3.9"
• Depth: 15.5"
• Width: 11.5"
• Weight: 7.9 lbs.
