PreSonus Studio 192 Mobile

Mi​crophone Preamp

• Type XLR Female (via Combo), Balanced Remote
• Maximum Input level (min. gain, 1 kHz@0.5% THD+N) +12 dBu, ±0.5 dB
• Gain Control Range 60 dB, ±1 dB
• Frequency Response (A-D) 10 Hz to 40 kHz, ±0.2 dB
• Dynamic Range (min. gain, a-wtd) > 110 dB
• Dynamic Range (mid. Gain, unwtd) > 105 dB
• THD+N (min. gain, a-wtd) < 0.005%
• Input Impedance 1.6 kΩ
• EIN (+55 dB gain, 150Ω input, 20 Hz-22 kHz, a-wtd) < 128 dBu
• Common Mode Rejection Ratio (1 kHz, +55dB gain) > 55 dB
• Phantom Power +48V, ±3V, > 8mA per channel

Instrument Inputs

• Type ¼” TS Female (via Combo), Unbalanced
• Maximum Input Level (min. gain, 1 kHz@0.5% THD+N) +16 dBu ±0.5 dB
• Gain Control Range 60 dB, ±1 dB
• Frequency Response (A-D) 20 Hz to 20 kHz, ±0.2 dB
• Dynamic Range (min. gain, a-wtd) > 110 dB dB
• Dynamic Range (mid. Gain, unwtd) > 105 dB
• THD+N (1 kHz, -1 dBFS, a-wtd) < 0.005%
• THD+N (1 kHz, -1 dBFS, un-wtd) < 0.005%
• Input Impedance > 1 MΩ
• Crosstalk (1 kHz, channel-to-channel) < -80 dB

Line Inputs

• Type ¼” TRS Female (via Combo), Balanced
• Maximum Input Level (min. gain, 1 kHz@0.5% THD+N) + 18 dBu, ±0.5 dB
• Frequency Response (A-D) 20 Hz to 20 kHz, ±0.2 dB
• Dynamic Range (min. gain, a-wtd) > 114 dB
• Dynamic Range (mid. gain, unwtd) > 105 dB
• THD+N (1 kHz, -1 dBFS, a-wtd) < 0.005%
• Input Impedance 10 kΩ
• Crosstalk (1 kHz, channel-to-channel) < -80 dB

Main and Line Outputs

• Type (Line Outputs) ¼” TRS Female, Impedance Balanced
• Type (Main Outputs) ¼” TRS Female, Impedance Balanced
• Maximum Output Level +18 dBu, ±0.5 dB
• Frequency Response 20 Hz to 20 kHz, ±0.2 dB
• Dynamic Range (a-wtd) > 112 dB
• THD+N (1 kHz, -1 dBFS, un-wtd) < 0.005%
• Output Impedance 51Ω
• Crosstalk (1 kHz, channel-to-channel) < -80 dB

Headphone Outputs

• Type ¼” TRS Female, Stereo, Unbalanced
• Maximum Output Level 150 mW/channel @ 60Ω
• Frequency Response 20 Hz to 20 kHz, ±0.3 dB
• Dynamic Range (a-wtd) > 103 dB
• THD+N (1 kHz, -1 dBFS, un-wtd) < 0.005%
• Crosstalk (1 kHz, channel-to-channel) < -80 dB

Signal Level LEDs

• Signal 1 -50 dBFS
• Signal 2 -30 dBFS
• Signal 3 -20 dBFS
• Signal 4 -10 dBFS
• Signal 5 -6 dBFS
• Signal 6 -4 dBFS
• Signal 7 -2 dBFS
• Clip -0.5 dBFS

Digital Audio

• Host Interface USB 3.0 (backwards compatible to USB 2.0)
• ADC Dynamic Range (A-wtd, 48 kHz) 118 dB
• DAC Dynamic Range (A-wtd, 48 kHz) 118 dB
• Bit Depth 24 bits
• Internally Supported Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
• ADAT Optical I/O ADAT/SMUX II formats supported [16x16 (44.1/48 kHz), 8x8 (88.2/96 kHz)]
• S/PDIF I/O RCA female connections, supported up to 96 kHz
• Word Clock I/O BNC connector, 4.5 Vpp @75Ω load

Clock

• Jitter <50 ps RMS (20 Hz – 20 kHz)
• Jitter Attenuation >60 dB (1 ns in => 1 ps out)

Power

• External Power Adapter +12 VDC, 3.0A, center positive
• Connector Type Barrel: 5.5 mm OD, 2.1 mm ID, 9.5 mm length

Physical

Dimensions
• Height 1.75” (44 mm)
• Depth 7” (178 mm)
• Width 12.5” (317 mm)
• Weight 5 lb. (2.3 kg)
